Grinding and Dispersion Technology
Grinding Beads
DYNO-BEADS Type Y
The zirconium oxide grinding beads with yttrium stabilization are characterized by their high density and hardness
Industries
Type Y
Zirconium oxide, yttrium stabilized grinding beads
The DYNO-BEADS made of zirconium oxide with yttrium stabilization are grinding media that are characterized by their high density and hardness. Thanks to their outstanding roundness and polished surface, these grinding beads not only offer exceptionally high wear resistance, but also reduce abrasion. This leads to a significantly longer service life for the machine components and reduces maintenance costs. All these properties lead to minimized product contamination and greater production efficiency.
Mechanical properties
| Specific weight | 6.05 kg/dm3 |
| Bulk density | 3.62-3.75 kg/dm3 |
| Young‘s modulus | 210 GPa |
| Microhardness HV10 | 1300 |
Technical specifications
| Article number | Ø [mm] | Article number | Ø [mm] |
|---|---|---|---|
| 261287 | 0.08 | 261294 | 0.80 |
| 261288 | 0.10 | 261295 | 1.00 |
| 261289 | 0.20 | 261296 | 1.25 |
| 261290 | 0.30 | 261297 | 1.50 |
| 261291 | 0.40 | 261298 | 1.75 |
| 261292 | 0.50 | 261299 | 2.00 |
| 261293 | 0.60 |
Type Y-XE
The DYNO-BEADS Y-Xtreme Endurance (XE) are characterized by their exceptional resistance to mechanical abrasion and their long service life, which makes them ideal for the most demanding applications where high loads and abrasive materials are processed.
Mechanical properties
| Specific weight | ≥ 5.95 kg/dm3 |
| Bulk density | 3.5-3.9 kg/dm3 |
| Young‘s modulus | 210 GPa |
| Microhardness HV10 | 1250 |
Technical specifications
| Article number | Ø [mm] | Article number | Ø [mm] |
|---|---|---|---|
| 261313 | 0.03 | 261319 | 0.50 |
| 261314 | 0.05 | 261320 | 0.65 |
| 261315 | 0.10 | 261321 | 0.80 |
| 261316 | 0.20 | 261322 | 1.00 |
| 261317 | 0.30 | 261323 | 1.25 |
| 261318 | 0.40 | 261324 | 1.50 |
Type Y-PHARMA
The pharmaceutical grade DYNO-BEADS Y have been specially developed for applications in the pharmaceutical industry to meet the high requirements for purity, quality, performance, certification and packaging.
Mechanical properties
| Specific weight | 6.05 kg/dm3 |
| Bulk density | 3.62-3.75 kg/dm3 |
| Young‘s modulus | 210 GPa |
| Microhardness HV10 | 1300 |
Technical specifications
| Article number | Ø [mm] | Article number | Ø [mm] |
|---|---|---|---|
| 261301 | 0.10 | 261306 | 0.70 |
| 261302 | 0.20 | 261307 | 0.90 |
| 261303 | 0.30 | 261308 | 1.10 |
| 261304 | 0.40 | 261309 | 1.30 |
| 261305 | 0.50 | 261310 | 1.50 |
Type Y-PHARMA-RTS
The DYNO-BEADS Y-PHARMA ready-to-sterilize (RTS) have been specially manufactured for use in sterile production environments and are equipped with autoclavable packaging that meets the highest hygiene requirements.
Mechanical properties
| Specific weight | 6.05 kg/dm3 |
| Bulk density | 3.62-3.75 kg/dm3 |
| Young‘s modulus | 210 GPa |
| Microhardness HV10 | 1300 |
Technical specifications
| Article number | Ø [mm] |
|---|---|
| 261311 | 0.20 |
| 261312 | 0.30 |
Download
Find more information about our grinding media DYNO-BEADS in compact form as PDF file. Optimum grinding beads for maximum efficiency and durability.
